Some industries, like furnace building industry, fossil power plants, refuse incinerators (garbage disposal plants) and chemical-/petrochemical industry, insulate materials up to 1200 °C which requires special insulation materials and insulation pins.
StwF offers great solutions for these applications such as a big range of high temperature insulation pins and clips, refractory anchors and welding machines.
| Materials Used: | Heat resistance on air up to …°C | Applications | ||
| Standard No. | (DIN)
Material |
AISI | ||
| 1.0116 | ST37-3 | ― | 350 °C | Sulphur Removal |
| 1.5415 | 15Mo3 | ― | 530 °C | Nitric Oxide Removal |
| 1.4301 | X5CrNi 1810 | 304 | 800 °C | Chimney Breeching |
| 1.4742 | X10CrAl18 | 446 | 1000 °C | Chimney Incinerator |
| 1.4841 | X15CrNiSi | 310 | 1150 °C | Chimney Furnace |
| 2.4851 | INCONEL60 | ― | 1250 °C | Furnace |
